torsion axle

Leaf Spring Trailer Axle Manufacturer

Haway the leading and reliable trailr torsion axles manufacturer in China. We supply torsion suspension axles capacity 2200 lb to 7000 lb.

There are full trailer torsion axle and half torsion trailer axle. Half torsion axle is and independent torsion axle as the right and left side are not connected together. Both kind of torsion alxe can be supplied by us.

Haway the leading and reliable trailr torsion axles manufacturer in China. We supply torsion suspension axles capacity 2200 lb to 7000 lb.

Choose Right Axle You Need

Part No.CapacityBolt PatternBrakeSurface TreatmentLength
SA22460002200 lbs5x4.5''NoBlack PaintedCustom Length
SA22470002200 lbs5x4.5''NoGalvanizedCustom Length
SA35460003500 lbs5x4.5''NoBlack PaintedCustom Length
SA35461002200 lbs5x4.5''Electric BrakeBlack PaintedCustom Length
SA35470003500 lbs5x4.5''NoGalvanizedCustom Length
SA35471003500 lbs5x4.5''Electric BrakeGalvanizedCustom Length
SA35560003500 lbs5x5''NoBlack PaintedCustom Length
SA35561002200 lbs5x5''Electric BrakeBlack PaintedCustom Length
SA35570003500 lbs5x5''NoGalvanizedCustom Length
SA35571003500 lbs5x5''Electric BrakeGalvanizedCustom Length
SA35572003500 lbs5x4.5''DiscBrakeBlack PaintedCustom Length
SA60560006000 lbs6x5.5''NoBlack PaintedCustom Length
SA60561006000 lbs6x5.5''Electric BrakeBlack PaintedCustom Length
SA60570006000 lbs6x5.5''NoGalvanizedCustom Length
SA60571006000 lbs6x5.5''Electric BrakeGalvanizedCustom Length
SA60572006000 lbs6x5.5''DiscBrakeGalvanizedCustom Length
SA70660007000 lbs8x6.5''NoBlack PaintedCustom Length
SA60561007000 lbs8x6.5''Electric BrakeBlack PaintedCustom Length
SA60570007000 lbs8x6.5''NoGalvanizedCustom Length
SA60571007000 lbs8x6.5''Electric BrakeGalvanizedCustom Length
SA60572007000 lbs8x6.5''Electric BrakeGalvanizedCustom Length
SA000000based on customer requirementbased on customer requirementbased on customer requirementbased on customer requirementCustom Length
We Supply Trailer Axles Mainly To Usa, Canada, Australia Markets For Many Years. All Axles Meet Local Market Standards.
Contact Us To Get Price Now
If you would like to know more about our products and services, complete the form below, and we will contact you as soon as possible to discuss your requirements.
*Email
Nombre
Teléfono
*Título
*Contenido
Subir
  • Solo admite .rar/.zip/.jpg/.png/.gif/.doc/.xls/.pdf, máximo 20M

Leaf Spring Shaft Application

Trailer torsion axle is a kind of trailer suspension system also called rubber torsion axle suspension. There are rubber cords in the axle beam tube to absorb the shocks. The rubber cords works as the same function as the trailer leaf springs. So the trailers with torsion axle kits do not need leaf springs. We supply ful length torsion axle and half torsion axles.
Trailer Yacht

Trailer Yacht

Trailer Yacht

Trailer Yacht

Trailer Yacht

Trailer Yacht

Trailer Yacht

Trailer Yacht

The Benefit Of Trailer Torsion Axle

1.No metal to metal contact points:
The torsion suspension axle are mounted or welded on the trailer frame directly. No leaf spring needed. So not like leaf spring trailer suspension, there is no metal to mental contact points.
2.Quite and smooth ride
Torsion axle is made up of axle beam, torsion bar and rubber cords. The torsion bar are surrounded by 4 rubber cords in the beam. When the wheel moves up and down, the rubber cords compress offering an even wheel suspension for smooth ride. As there is no metal to metal contact it has a quite ride too.
3.Torsion trailer axle kit is safer
Unlikely leaf spring suspension there a many connecting points, torsion suspension trailer axle is bolted on or welded on trailer frame directly, which connected with trailer rigidly. if the suspension fails, the torsion the torsion axle kits can't detach itself from the trailer bed. But when break a leaf spring, A detachment can happen when a spring breaks on a standard trailer suspension.
4.Do not need much maintenance.
There are fewer working parts in the rubber torsion axle suspension units therefore less maintenance is required. Just need to bolt points about half a year.
5.Half torsion axle are best choice for custom trailers
Half torsion axle comes in two parts, the right and left side. The two sides do not span the width of the trailer. So half torsion axle are perfect for custom trailers.
